Model
Indoor (50 Hz) CS-PN18XKH-1
Outdoor CU-PN18XKH-1
–
Cooling Capacity (min-max)
5.33 kW
18,200 Btu/h
–
EER (min-max)
11.23 Btu/hW
3.29 W/W
CSPF 3.49 W/W
–
Electrical Data
Voltage 230 V
Current 7.1 A
Power Input (min-max) 1,620 W
–
Moisture Removal
2.9 L/h
6.1 Pt/h
–
Air Circulation
Indoor 18.4 m³/min (650 ft³/min)
Outdoor 39.3 m³/min (1,390 ft³/min)
–
Noise Level
Indoor (H / L) 43/39 dB(A)
Outdoor (H) 53 dB(A)
–
Dimensions (Indoor)
Height 295 mm (11-5/8 inch)
Width 1,040 mm (40-31/32 inch)
Depth 244 mm (9-5/8 inch)
–
Dimensions (Outdoor)
Height 619 mm (24-3/8 inch)
Width 824 mm (32-15/32 inch)
Depth 299 mm (11-25/32 inch)
–
Net Weight
Indoor 12 kg (26 lb)
Outdoor 35 kg (77 lb)
–
Refrigerant Pipe Diameter
Liquid Side ø 6.35 mm (1/4 inch)
Gas Side ø 12.70 mm (1/2 inch)
–
Pipe Extension
Chargeless Pipe Length 7.5 m
Maximum Pipe Length 30 m
Maximum Elevation Length 20 m
Additional Refrigerant Gas* 15 g/m
–
Power Supply – Indoor
